Modularity Through The Ages

In the last post, we explored the timeless push and pull between coupling and cohesion. We established them as the key metrics for a healthy, modular system. But this struggle is not new. In fact, it is one of the central, driving forces in the history of software architecture.

To truly master these principles, we must see them not as abstract theory, but as the fundamental problem that generations of developers have tried to solve. In this post, we’ll put our current challenges in context by taking a journey through the ages of software design, exploring how the constant pursuit of modularity has shaped our industry.

We have to start somewhere; let’s start at the beginning by asking the fundamental question - What do we want our software to achieve?

The bare minimum is business functionality. The thing is, businesses go through changes, some more than others. Our software need to change at the same rate. Making changes to our software is a lot harder than it seems. The ‘code’ that makes up the software is to be understood by humans before changing. Making code easier to understand and easier to change, thus, is fundamental to software development.

What makes software hard to change? Sometimes changes made in one area of the codebase can have unintended consequences elsewhere. There is often the need to make other coordinated changes in other parts of the codebase. It is so much better if the related changes were local and not in an seemingly unrelated part.

We want related code to be close together and no unintended consequences elsewhere. This is Coupling and Cohesion in action. This is the basis for good modular design. Coupling describes how modules in software depend on each other, while cohesion tells you how closely related functions are within a module. Our aim, as software developers, is to achieve low coupling (independent modules) and high cohesion (focused functions).

Modules

A module is a collection of related code. It could be a function, a class**,** a**** library, a package, a process, a thread, etc. In effect, anything that has a well defined functionality is a module. Your browser’s sandbox is a module. Containers, virtual machines, and OS Kernels are also modules.

Modules on their own are of little use. What can a single function or an object achieve? They need to somehow communicate with other modules. You have APIs, system calls, sockets, RPCs, file systems, databases, message passing systems, etc. This defines their interface.

What does it mean for a module to have low coupling? Coupling is a measure of interdependence between modules. For example, if module A depends on internal details of other module B to work, then, whenever module B changes your module A also has to undergo changes accordingly. We say the two modules are highly coupled. There will always be some coupling since they need to communicate to work together; the aim is to minimise the interdependence.

Module Isolation

True low coupling goes beyond just interfaces. We need to actively isolate modules, minimising dependencies and preventing unintended interactions. This creates self-contained units with well-defined boundaries, akin to Lego blocks. You can combine, replace, or upgrade individual modules without impacting the entire system.

The initial developers carefully designed their modules and painstakingly come up with a module structure and directed (dictated?) which modules depend on which other module. All it takes to break this carefully crafted module dependency is a simple import statement.

When the entire app is a single bundle, aka a monolithic build , how do you avoid such un-intended consequences? Especially when there are multiple teams working on the app? One way is to isolate your modules such that others are forced to only rely on its interface. That calls for a strong module isolation where one cannot bypass the provided interface even intentionally.

Strong isolation, however, is usually thought of as a security measure and not to avoid intentional short-cuts from a developer in a hurry. Whatever the case maybe, we had a solid understanding of how to build modular application that are easy to understand and easy to change.

Then, from here on, where we had good modular design, why did we change?

Time For Some History

In early 1980s the most common processors were 16-bit processors with a 64K address space. There is only so much that one could fit into such a machine. Remote Procedure Calls (RPCs) was the first major systems distribution technology. The basic idea was to make remote calls transparent to developers. The promise was that if developers didn’t have to care whether the procedure calls or methods they were invoking were local or remote, then they could build larger systems, crossing machine boundaries, that could avoid the processing and memory scalability issues that affected systems of the time.

RPCs paved the path for DCE and CORBA, but as technology improved, developers learned that distributed communication doesn’t always translate to better performance. Frequent communication between distributed components, known as “chattiness,” can create significant network overhead, outweighing the benefits.

To address this challenge, the Facade pattern emerged as described in the Gang of Four (GoF) book. This design pattern simplifies communication by encapsulating a complex system’s inner workings behind a single, well-defined interface, thereby reducing coupling between the client and the complex subsystem. This reduces “chattiness” and improves overall performance.

The Facade pattern ultimately influenced the development of Enterprise Java Beans (EJBs). Interoperability was a major concern with EJBs. The next iteration, to solve the problems of EJBs was the Service Oriented Architecture (SOA). SOA originally began as a ”do the simplest thing that could possibly work" effort called Simple Object Access Protocol (SOAP) - a way of invoking object methods over HTTP.

Instead of just calling a function, things got fancy very quickly. SOA soon got bogged down with extra stuff like error handling, transactions, security, digital signatures, etc. (WS-*). It became too complicated for its own good.

A Ph.D. dissertation in 2000 by Roy Fielding set the foundational principles for REST, articulating a new architectural style that would profoundly influence how we build web services. Instead of layering procedural semantics onto the HTTP transport, REST uses the inherent semantics of HTTP verbs for create, read, update, and delete operations. Additionally, it defines a mechanism for identifying resources utilising URIs.

Another unintended consequence of this progressive transition from RPCs to REST services is increased complexity in maintaining and running multiple runtime environments. Even though services were developed individually in isolation, they were supposed work with and tested alongside other services. When changes were made to multiple services, their testing and release took forever as multiple environments were needed and it took much time and effort.

Realisation hits the developers again.Programs and their runtime environments should be entirely self-contained. All these observations are then brought under a single set of principles called “Microservices.”

Monoliths And Microservices

The technological landscape may have shifted from RPCs, CORBA, EJBs, SOA to Microservices, but the underlying principle remains unchanged: modularity. Whether we’re bundling application as a single unit or spreading services across distributed network of machines, the key to maintainability and scalability lies in well-defined modules with minimal dependencies. Strong code cohesion, low coupling, and clear contracts are the timeless steps to a healthy system, regardless of its deployment structure.

However, the pursuit of microservices often leads to a common anti-pattern: the “distributed monolith.” This occurs when a system is physically deployed as multiple services, but these services remain tightly coupled at a logical level. They might share a single database, have synchronous dependencies, or require coordinated deployments. The result is a system that carries the operational overhead of distributed systems without gaining the benefits of independent deployability and evolvability. It’s a stark reminder that simply splitting code into separate processes does not automatically confer modularity; the underlying principles of information hiding, loose coupling, and high cohesion must still be rigorously applied to any architectural style.

Build (and Deployment) is where the difference between the human aspect (the code) and the machine aspect (the build/binary/software) is visible. We organise and mange them differently. The code is written by and is to be understood by humans. It deals with repositories, repositories, projects, modules and dependencies. The runtime or deployment deals with what production environments look like and how deployable run in them.

In a monolithic setup one or more repositories build one deployable artefact. When the industry moved away from from this monolithic approach to microservices, we, like before when we were given RPCs, took it to the extreme. We split the codebase and the deployable alike. We split code according to runtime concerns, and/or the deployable in line with project concerns. We threw module dependencies out the window. The dependency graphs are basically non existent. We coupled our project and deployment models, our repositories and our services, the way we organise our code and the way our services are run. The way teams are organised is dictating our code structure. Project/code structure is dictating our deployment structure. As a result modules that were supposed to be cohesive unit were broken down, the dependent modules were separated into a ‘independent’ deployable unit/service.

Modularity And Architectures

Throughout the evolution of software architecture, one principle has remained constant: the importance of modular code. Irrespective which architectural pattern you are currently working/dealing with, unless you have modular code, you are going to feel the pain. Monoliths are monoliths not because they lack modularity but instead they are single bundle. Yes, monoliths did connect and work with multiple data sources. No, entire application need not crash because one DB failed. They knew how to handle error gracefully. Active-Passive, Active-Active failover and DR mechanisms did exist. There were challenges and problems, of course. But these were not the important ones.

And no, the prominent aspect of microservices is not that it lets you split up your application into multiple smaller chunks. More than anything the usefulness of microservices is that it not only encapsulates (in a sense) data and the code that works with it, it also isolates them in a service boundary.

Brand new microservices (or Hexagonal, or Hub-and-Spokes, or..) architecture is bound to cause more pain than bring benefits if you are not careful while designing your module/service/component.

This history teaches us that while technologies and buzzwords change, the principles of modular design are timeless. To see this in action, our journey continues with a deep dive into two classic, contrasting architectural styles. In the next post, we will analyze Remote Procedure Calls (RPCs) through the lens of modularity we’ve developed so far.
