My recent escapade with Python taught me many things. One of which is to “start doing something that interests you. And each such daring act will teach you many more things.”
This time I set out to finding ways of analysing the performance of an application - specifically Python applications. And as always I wasn’t disappointed with the results. Why Python? I just happened to be playing around with Python at the time (what I really mean is I was learning Python! ).
Performance Analysis
Let us start by trying to understand what is performance and how do we analyse it.
- Performance is a measure of how fast the application (or each component of the application) is running and how little memory it uses
- Performance analysis is finding where are the speed bottlenecks and where is the memory leaking
In this article we will restrict ourselves to measuring and analysing the performance. Improving performance is a different topic altogether. Hopefully, I will have something to write about it someday. Depending on the need of the hour, you can choose any one or a combination of the tools and techniques explained here.
Good old ‘time’
I use a Mac, but I am pretty sure, the time utility came from Unix ancestry.
$ time python slowprogram.py
python slowprogram.py 3.81s user 0.04s system 97% cpu 3.927 total
The sum of user and system time gives you a measure of how much time your program took (excluding time taken for I/O).
This doesn’t help much. Though this tells you that the application is taking more time than it should be taking (how do you know?), it doesn’t tell you where so that you can go look.
Python Timer Class - Context Manager
Corey Goldberg, in his blog here, has given a tiny timer class that can be used to time any block of code.
from timeit import default_timer
class Timer(object):
def __init__(self, verbose=False):
self.verbose = verbose
self.timer = default_timer
def __enter__(self):
self.start = self.timer()
return self
def __exit__(self, *args):
end = self.timer()
self.elapsed_secs = end - self.start
self.elapsed = self.elapsed_secs * 1000 # millisecs
if self.verbose:
print 'elapsed time: %f ms' % self.elapsed
With this class in hand all you need to do is to enclose any code within the with block -
from timer import Timer
from sorting import Sort
import random
random_items = [random.randint(-50, 100) for c in range(5000)]
sort = Sort()
with Timer() as t:
sort.bubble_sort(random_items)
print "=> elapsed bubble_sort: %s s" % t.elapsed
with Timer() as t:
sort.insertion_sort(random_items)
print "=> elapsed insertion_sort: %s s" % t.elapsed
Here is a sample output :
$ python UsingTimer.py
=> elapsed bubble_sort: 4177.52599716 s
=> elapsed insertion_sort: 1.23190879822 s
The advantage with this approach is obvious. You can enclose any suspicious piece of code inside the with block and see if that block of code is taking too long to complete. You would first start with enclosing a bigger chunk and keep on reducing the size to pin-point the problematic part.
Profiling
A profile is a set of statistics that describes how often and for how long various parts of the program get executed. The time utility described above is also a profiler - a simple one whose stats output is not very detailed.
The Python standard library provides three different implementations of the same profiling interface. The documentation is available here.
Simple approach
Simple way to profile a script is to invoke the cProfile when running a script:
$ python -m cProfile UsingTimer.py
This prints the stats onto standard out.
=> elapsed bubble_sort: 4173.29096794 s
=> elapsed insertion_sort: 2.54702568054 s
25073 function calls in 4.231 seconds
Ordered by: standard name
ncalls tottime percall cumtime percall filename:lineno(function)
1 0.006 0.006 4.231 4.231 UsingTimer.py:1(<module>)
1 0.000 0.000 0.000 0.000 __future__.py:48(<module>)
1 0.000 0.000 0.000 0.000 __future__.py:74(_Feature)
7 0.000 0.000 0.000 0.000 __future__.py:75(__init__)
1 0.017 0.017 0.017 0.017 hashlib.py:55(<module>)
6 0.000 0.000 0.000 0.000 hashlib.py:94(__get_openssl_constructor)
1 0.002 0.002 0.002 0.002 heapq.py:31(<module>)
1 0.000 0.000 0.001 0.001 random.py:100(seed)
5000 0.011 0.000 0.011 0.000 random.py:175(randrange)
5000 0.003 0.000 0.014 0.000 random.py:238(randint)
1 0.008 0.008 0.026 0.026 random.py:40(<module>)
1 0.000 0.000 0.000 0.000 random.py:655(WichmannHill)
1 0.000 0.000 0.000 0.000 random.py:72(Random)
1 0.000 0.000 0.000 0.000 random.py:805(SystemRandom)
1 0.000 0.000 0.001 0.001 random.py:91(__init__)
1 0.001 0.001 0.003 0.003 sorting.py:1(<module>)
1 0.002 0.002 0.003 0.003 sorting.py:11(insertion_sort)
1 0.000 0.000 0.000 0.000 sorting.py:3(Sort)
1 4.084 4.084 4.173 4.173 sorting.py:4(bubble_sort)
1 0.000 0.000 0.000 0.000 timeit.py:105(Timer)
1 0.005 0.005 0.005 0.005 timeit.py:53(<module>)
1 0.001 0.001 0.006 0.006 timer.py:1(<module>)
2 0.000 0.000 0.000 0.000 timer.py:12(__exit__)
1 0.000 0.000 0.000 0.000 timer.py:3(Timer)
2 0.000 0.000 0.000 0.000 timer.py:4(__init__)
2 0.000 0.000 0.000 0.000 timer.py:8(__enter__)
1 0.000 0.000 0.000 0.000 {_hashlib.openssl_md5}
1 0.000 0.000 0.000 0.000 {_hashlib.openssl_sha1}
1 0.000 0.000 0.000 0.000 {_hashlib.openssl_sha224}
1 0.000 0.000 0.000 0.000 {_hashlib.openssl_sha256}
1 0.000 0.000 0.000 0.000 {_hashlib.openssl_sha384}
1 0.000 0.000 0.000 0.000 {_hashlib.openssl_sha512}
1 0.000 0.000 0.000 0.000 {binascii.hexlify}
1 0.001 0.001 0.001 0.001 {function seed at 0x109498d70}
6 0.000 0.000 0.000 0.000 {getattr}
6 0.000 0.000 0.000 0.000 {globals}
5002 0.001 0.000 0.001 0.000 {len}
1 0.000 0.000 0.000 0.000 {math.exp}
2 0.000 0.000 0.000 0.000 {math.log}
1 0.000 0.000 0.000 0.000 {math.sqrt}
1 0.000 0.000 0.000 0.000 {method 'disable' of '_lsprof.Profiler' objects}
5000 0.001 0.000 0.001 0.000 {method 'random' of '_random.Random' objects}
1 0.000 0.000 0.000 0.000 {posix.urandom}
5003 0.089 0.000 0.089 0.000 {range}
4 0.000 0.000 0.000 0.000 {time.time}
From this we can figure out which module and function is heavily used and try to either improve that function or take other design decisions to reduce the number of calls to that function.
In the above example, clearly, bubble sort is taking too much time. See for yourself:
ncalls tottime percall cumtime percall filename:lineno(function)
1 4.084 4.084 4.173 4.173 sorting.py:4(bubble_sort)
Profiling a single statement
Sometimes it is not a good idea or not required/possible to profile an entire script. In those scenarios you can profile individual statements:
cProfile.run('sort.bubble_sort(random_items)')
The stats, as before, are printed on to standard out.
$ python cprofile_simple.py
10005 function calls in 3.732 seconds
Ordered by: standard name
ncalls tottime percall cumtime percall filename:lineno(function)
1 0.000 0.000 3.732 3.732 <string>:1(<module>)
1 3.653 3.653 3.732 3.732 sorting.py:4(bubble_sort)
5001 0.001 0.000 0.001 0.000 {len}
1 0.000 0.000 0.000 0.000 {method 'disable' of '_lsprof.Profiler' objects}
5001 0.079 0.000 0.079 0.000 {range}
Profiling Memory Usage
Till now we only concerned ourselves with how long it takes to complete a task, whether it be a statement, a function call or an entire script. Now we will see how to profile memory usage of a python script.
I will show you a few examples of memory profiling using the memory_profiler package.
$ pip install -U memory_profiler
memory_profiler requires that you decorate your function of interest with an @profile decorator:
$ python memprofile_sample.py
Filename: memprofile_sample.py
Line Mem usage Increment Line Contents
10 8.7 MiB 0.0 MiB @profile
11 def test():
12 9.2 MiB 0.4 MiB sort.bubble_sort(random_items)
13 9.2 MiB 0.0 MiB sort.insertion_sort(random_items)
14 9.3 MiB 0.2 MiB sort.quick_sort(random_items)
15 9.4 MiB 0.0 MiB sort.heap_sort(random_items)
The first column represents the line number of the code that has been profiled, the second column (Mem usage) shows the memory usage of the Python interpreter after that line has been executed. The third column (Increment) represents the difference in memory of the current line with respect to the last one. The last column (Line Contents) prints the code that has been profiled.
Memory Leak
Python uses reference counting to keep track of objects in use. What this means is each of the objects that the application creates holds a numeric count. This count represents the number of references to an object at any given time. The count is incremented every time a new reference to the object is created and decremented when a reference is deleted. This way, when the ref-count of an object becomes zero, the Python interpreter knows that the object is no longer required and can be destroyed, thus reclaiming the memory used by that object.
If Python automatically handles deleting unwanted objects how does the memory leak?
The only way for the Python interpreter to know that an object is unwanted is by looking at the number of references the object has. If the developer of the script is not careful in removing those unwanted references, there is no way for Python to destroy the object and reclaim memory. So, basically, it is a human fault (No surprises there!).
How do I know if my application is leaking memory? Well, intuitively, if the memory usage of the application grows over time but the amount of data it holds remains the same, there is memory leak.
All the code used in this article is available here
